Product Introduction
Core Features
Compact size
Narrow body width (less than 1 meter), suitable for narrow space (such as indoor, courtyard, laneway) operation.
Can be equipped with rubber tracks or wheeled chassis to reduce damage to the ground.
Flexible operation
Most support 360° rotation, equipped with tailless design (Tail Swing Reduction) to avoid collision with obstacles during rotation.
Multi-function hydraulic quick-change interface, can quickly switch buckets, breakers, drills and other accessories.
Power type
Electric type: zero emission, low noise, suitable for indoor or environmental protection areas.
Diesel type: more powerful, suitable for field or long-term operation.
Common application scenarios
Landscaping: digging tree pits and landscaping.
Indoor demolition: concrete crushing and wall demolition.
Pipeline laying: trench excavation.
Rural construction: small-scale farmland water conservancy and biogas tank construction.
Technical Parameters
Vehicle weight | 1500KG | engine | Kubota D722 |
Dimensions | 2200*1100*2203MM | Engine power | 10.2KW |
Track width | 180MM | Euro 5 & EPA4 engine optional | Kubota D722 |
Track ground contact length | 1300MM | Maximum digging height | 3016.52MM |
Chassis ground clearance | 385MM | Maximum dumping height | 2133.98MM |
Bucket capacity | 0.04M³ | Maximum digging depth | 2047.06MM |
Gradeability | 40° | Maximum digging radius | 3450.31MM |
Fuel tank capacity | 16L | Radius of rotation | 1636MM |
Hydraulic oil tank capacity | 16L | Configuration | Hydraulic pilot operated Four-legged ceiling Taifeng load sensing piston pump and multi-way valve Big arm side swing, chassis extension High and low speed |
Hydraulic flow | 50L/Min | ||
Work Pressure | 16Mpa |
