Product Introduction
Core Features
Compact size
Narrow body width (less than 1 meter), suitable for narrow space (such as indoor, courtyard, laneway) operation.
Can be equipped with rubber tracks or wheeled chassis to reduce damage to the ground.
Flexible operation
Most support 360° rotation, equipped with tailless design (Tail Swing Reduction) to avoid collision with obstacles during rotation.
Multi-function hydraulic quick-change interface, can quickly switch buckets, breakers, drills and other accessories.
Power type
Electric type: zero emission, low noise, suitable for indoor or environmental protection areas.
Diesel type: more powerful, suitable for field or long-term operation.
Common application scenarios
Landscaping: digging tree pits and landscaping.
Indoor demolition: concrete crushing and wall demolition.
Pipeline laying: trench excavation.
Rural construction: small-scale farmland water conservancy and biogas tank construction.
Technical Parameters
| Vehicle weight | 1000KG | engine | Huapuri 192F |
| Dimensions | 2200*1100*2200MM | Engine power | 14horsepower |
| Track width | 180MM | Euro 5 & EPA4 engine optional | Popular Science 192, Briggs & Stratton |
| Track ground contact length | 1030MM | Maximum digging height | 2550MM |
| Chassis ground clearance | 385MM | Maximum dumping height | 1710MM |
| Bucket capacity | 0.025M³ | Maximum digging depth | 1740MM |
| Gradeability | 30° | Maximum digging radius | 3100MM |
| Fuel tank capacity | 5L | Radius of rotation | 1635MM |
| Hydraulic oil tank capacity | 12L | Configuration | Load-sensitive pump valve, dual swing motor Standard configuration Two-leg roof Dual pump Load-sensitive Track: 180*37*41 Hydraulic pilot operation |
| Hydraulic flow | 18L/Min/27L/Min | ||
| Work Pressure | 16Mpa |
