Maximum Load Capacity(T)

0.8

Bucket Rated Capacity(M)³

0.3

Dumping Height(MM) (At 45°)

1780

Lifting Height(MM)

3140

Dumping Reach(MM)

980

Max. Lifting Weight(KG)

600

Max. Excavation Force(KN)

1000

Max. Grade Ability

30°

Max. Turning Angel

30°±1

Swing Degree Of The Rear Axle

7°

Dimensions. &.Weight

Overall Length(Bucket on Ground Position)MM

3840

Bucket Width(Overall Width)

1280

Overall Height(MM)

2350

Wheel Base(MM)

850

Min Ground Clearance(MM)

240

Net Weight(KG)

2380

Battery

Battery Model No.

6-EVF-203A

Rated Capacity(3HR)

200Ah

No.Of Battery Groups

12

Rated Voltage

72V

Working Hours(H)

4-5h

Transmission System

Hydraulic System

Motor No.

CBHV

Voltage

72V

Power

5000W

Displacement(ML/R)

18

Tyres

Type

26*1200-12

Working Pressure(MPA)

0.3

Qty

4

Power

4000W

Steering System

Type of Steering Hydraulic System

Full Hydraulic Steering System

System Pressure(mpa)

16

Type of Steering Pump

External Gear Pump

Steering Cylinder Bore(MM)

63

Qty(PC)

1

Braking System

Service Brake

Drum Brake

Brake Drum(MM)

250

Parking Brake

Drum Brake

Distribution Valve

Model

DL10

Type

Triple valve stem

Dumping Cylinder-Bore

Ø80

Lifting Cylinder-Bore

Ø63

Oil Capacity

Hydraulic Oil Tank(L)

30

Brake Fluid(L)

0.8
